32-Channel H.264 Networked High Definition CCTV Video Recorder with SD card backup
Brand: Anglian Video
Product Code: SDDVRW16
Reward Points: 69
Shipping & Handling: 5-7 Working Days to Your Door
Product Features:
1. Standard H.264 compression,efficient processing capabilities,high definition image quality.
2. Display Frame Rate:NTSC:960fps/ PAL:800fps,Recording Frame Rate:NTSC:480fps / PAL:400fps.
3. Dual-stream design,network remote view effects and local recording effects parameters can be set separately,independently of each other.
4. 32CH Video input,2CH Video output; 8ch audio-in,1ch audio-out; 8ch alarm-in,1ch alarm-out
5. Multiplex function: Live display, record, playback,and network live,playback,backup simultaneously,independently of each other.
6. Support Multiple channel playback simultaneously,to facilitate comparison the different channels of recording(Support 16CH playback simultaneously,and each channel can be enlarge to full screen).
7. Super Network function:one IE browser centralized monitoring and CMS Software for multiple DVR (up to control 255 DVR simultaneously).
8. Supports Multiple backup mode:USB flash drive,USB hard disk,network and SATA DVD_R/W, SD card backup.
9. Support full control through USB Mouse,finishing all the setup and operation.
10. Support remote view by Mobilephone(support Symbian S60;Windows CE;Iphone;Blackbery and Andriod system.)
11. Support 2 SATA HDD,unlimited for the capacity
12. Support PTZ control via built-in RS-485 port
13. Support VGA output; (HDMI output (Optional)
14. System auto recovery to power after power reconnected,and return to the pre-power-down state
| CCTV DVR | |
| Compression | H.264 |
| Video Format | NTSC / PAL |
| Video Input | 32×BNC(1.0Vp-p, 75Ω) |
| Video Output | 2×BNC(1.0Vp-p, 75Ω)；1×VGA |
| SPOT Output | N/A |
| LOOP Output | N/A |
| HDMI Output Resolution | 1920×1080(optional) |
| YPbPr Output Resolution | N/A |
| VGA Output Resolution | 1280×1024 |
| Live Frame Rate | 32 ×25fps(PAL), 32×30fps(NTSC) |
| Network Resolution/fps | ＞10 fps /channel @ CIF resolution |
| Record | NTSC:960fps / PAL:800fps |
| Playback | NTSC:960fps / PAL:800fps |
| CIF Record Frame Rate | NTSC:960fps / PAL:800fps |
| Audio | 8ch audio-in,1ch audio-out |
| Alarm Input | 8ch alarm-in,1ch alarm-out |
| Alarm Output | Relay output: Normal open (NO); Normal close (NC); COM |
| Alarm Mode | Disk full alarm; motion detection alarm |
| Remote Control | Yes |
| Record Mode | Time/sensor/motion detection |
| Network Port | 1 x 100M RJ-45 |
| USB Port | 2×host 2.0 |
| Hard Disk | Support 2 SATA HDD,unlimited for the capacity |
| DVD-RW | USB |
| PTZ Control | RS-485 |
| Power Supply | AC220V(110V) |
| Operating Temperature | -10℃--＋55℃ |
| Operating Humidity | 10％--90％ |
