24-Channel H.264 Networked High Definition CCTV Video Recorder with HDMI output
Brand: Anglian Video
Product Code: SDDVRW24
Reward Points: 55
Shipping & Handling: 5-7 Working Days to Your Door
Product Features:
1. Standard H.264 compression,efficient processing capabilities,high definition image quality.
2. Display Frame Rate:NTSC:720fps/ PAL:600fps,Recording Frame Rate:NTSC:480fps / PAL:400fps.
3. Dual-stream design,network remote view effects and local recording effects parameters can be set separately,independently of each other.
4. 24CH Video input,2CH Video output; 8ch audio-in,1ch audio-out; 8ch alarm-in,1ch alarm-out
5. Multiplex function: Live display, record, playback,and network live,playback,backup simultaneously,independently of each other.
6. Support Multiple channel playback simultaneously (Support 16CH playback simultaneously,and each channel can be enlarge to full screen).
7. Super Network function: IE browser monitoring and CMS Software for multiple DVR (up to 255 DVR simultaneously).
8. Supports Multiple backup media:USB flash drive,USB hard disk,network and SATA DVD_R/W, SD card backup.
9. Support full control through USB Mouse.
10. Support remote login by Mobile(support Symbian S60;Windows CE;Iphone;Blackbery and Andriod system.)
11. Support 2 pcs SATA HDD,unlimited for the capacity
12. Support PTZ control via built-in RS-485 port
13. Support VGA output; (HDMI output)
CCTV DVR | |
Compression | H.264 |
Video Format | NTSC / PAL |
Video Input | 24×BNC(1.0Vp-p, 75Ω) |
Video Output | 2×BNC(1.0Vp-p, 75Ω);1×VGA |
SPOT Output | N/A |
LOOP Output | N/A |
HDMI Output Resolution | 1920×1080(optional) |
YPbPr Output Resolution | N/A |
VGA Output Resolution | 1280×1024 |
Live Frame Rate | 24 ×25fps(PAL), 24×30fps(NTSC) |
Network Resolution/fps | >10 fps /channel @ CIF resolution |
Record | CIF:352*240 pixels with 720 IPS <NTSC> /352*288 pixels with 600 IPS <PAL> QCIF:176*200 pixels with 720 IPS <NTSC> /176*144 pixels with 600 IPS <PAL> |
Playback | CIF: 600fps(PAL)/720fps(NTSC) |
CIF Record Frame Rate | 600fps(PAL)/720fps(NTSC) |
Audio | 8ch audio-in,1ch audio-out |
Alarm Input | 8ch alarm-in,1ch alarm-out |
Alarm Output | Relay output: Normal open (NO); Normal close (NC); COM |
Alarm Mode | Disk full alarm; motion detection alarm |
Remote Control | Yes |
Record Mode | Time/sensor/motion detection |
Network Port | 1 x 100M RJ-45 |
USB Port | 2×host 2.0 |
Hard Disk | Support FOUR SATA HDD,unlimited for the capacity |
DVD-RW | USB |
PTZ Control | RS-485 |
USB Mouse | Yes |
Power Supply | AC220V(110V) |
Operating Temperature | -10℃--+55℃ |
Operating Humidity | 10%--90% |
